How to remove and install the Power Steering Pump for the Honda Crosstour?

Use shop towels to protect engine components from spilled fluid during this procedure. Clean any spilled fluid immediately. On V6 models, remove the engine mount bracket on the right side of the engine, if equipped. Remove the drivebelt. Place a clamp on the power steering feed hose to minimize fluid loss when the hose is disconnected, then disconnect the fluid hoses at the pump. Note the difference between the pressure and the return (feed) hoses; the return hose is held to the pump with a spring type clamp, and the pressure line has two bolls holding it to the pump body. Cap or plug both hoses to prevent leakage or contamination. Install a new 0-ring on the end of the pressure line. Remove the pump mounting bolls and then remove the pump from the engine. Installation is the reverse of removal. Be sure to bleed the power steering system.

Genuine Honda Crosstour Power Steering Pump

Power Steering Pump Unit

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

3 Power Steering Pumps found

View related parts
Honda Crosstour Pump Sub-Assembly, Power Steering
Part Number: 56110-R70-A12
$534.04 MSRP: $770.62
You Save: $236.58 (31%)
ADD TO CART
Product Specifications
- Other Name: Power Steering Pump
- Replaces: 56110-R70-A11
- Warranty: This genuine part is guaranteed by Honda's factory warranty.
Fits the following Vehicles:
- 2010-2012 Honda Crosstour | 5 Door EX (2WD), 5 Door EX-L (2WD), 5 Door EX-L (4WD) | KA 5AT
View related parts
Honda Crosstour Pump, Reman
Part Number: 06561-R70-505RM
$316.95 MSRP: $447.75
You Save: $130.80 (30%)
ADD TO CART
Product Specifications
- Other Name: Power Steering Pump
- Replaces: 56100-R70-A12RM
- Warranty: This genuine part is guaranteed by Honda's factory warranty.
Fits the following Vehicles:
- 2010-2012 Honda Crosstour | 5 Door EX (2WD), 5 Door EX-L (2WD), 5 Door EX-L (4WD) | KA 5AT
View related parts
Honda Crosstour Pump Assembly, Power Steering (L4) (Coo)
Part Number: 56100-5J0-315
$431.76 MSRP: $623.04
You Save: $191.28 (31%)
ADD TO CART
Product Specifications
- Other Name: Power Steering Pump
- Replaces: 56100-5J0-A01, 56100-5J0-305
- Warranty: This genuine part is guaranteed by Honda's factory warranty.
Fits the following Vehicles:
- 2012-2015 Honda Crosstour | 5 Door EX, 5 Door EX-L | KA 5AT

About Honda Crosstour Power Steering Pump

A Honda Crosstour needs to be kept in good working condition in your vehicle. The online catalog we provide will get you through the ordering process safely and securely. All genuine Honda Power Steering Pumps from us are shipped directly from authorized Honda Dealer. If you want search for Honda Power Steering Pump fast and easily, just come to Hondapartsnow.com to look for your parts.

Honda Crosstour Power Steering Pump Parts Questions & Experts Answers

Pump Sub-Assembly, Power Steering
56110-R70-A12
Q: How to remove and install the Power Steering Pump for the Honda Crosstour?
A: Use shop towels to protect engine components from spilled fluid during this procedure. Clean any spilled fluid immediately. On V6 models, remove the engine mount bracket on the right side of the engine, if equipped. Remove the drivebelt. Place a clamp on the power steering feed hose to minimize fluid loss when the hose is disconnected, then disconnect the fluid hoses at the pump. Note the difference between the pressure and the return (feed) hoses; the return hose is held to the pump with a spring type clamp, and the pressure line has two bolls holding it to the pump body. Cap or plug both hoses to prevent leakage or contamination. Install a new 0-ring on the end of the pressure line. Remove the pump mounting bolls and then remove the pump from the engine. Installation is the reverse of removal. Be sure to bleed the power steering system.
